Price From

N/A

Power

102.0 CV @ 7500 rpm

Max. Torque

98.3/6500

Curb Weight (KG)

510

All-Terrain Ready Chassis
Built on a robust Cr-Mo steel frame with an integrated steel-tube handlebar, an 80.5° approach angle and 300mm of ground clearance, the REDSTONE 1000 R2 DL is engineered to handle the harshest trails without giving up stability or control.
997.1cc DOHC V-Twin Engine | 102 CV of Power
A 997.1cc 4-stroke DOHC V-Twin engine with EFI and liquid cooling delivers 75kW (102 CV / 100.5 HP) at 7,500 rpm and 98.3 N·m of torque at 6,500 rpm, paired with a smooth CVT gearbox and shaft drive for confident power delivery on any terrain.
Selectable 2WD/4WD with Turf Mode Diff-Lock
Switch between 2WD and 4WD with a locking rear differential, then engage Turf Mode to unlock the differential for tighter turns without tearing up the ground, giving riders precise control on grass, dirt, or rock.
Long-Travel Suspension
A Dual A-Arm front suspension with sway bar and an Independent Torsional Trailing Arm rear suspension, both with 230mm of travel and adjustable gas shocks, keep the REDSTONE planted and in control, balancing comfort and stability over rough ground.
Heavy-Duty Winch
A steel rope winch delivers industry-leading pulling power with a 15-24 meter cable, ready to recover the REDSTONE or lend a hand wherever the trail gets tough.
Cargo & Payload Capacity
With a 795kg payload capacity, 45kg front and 90kg rear rack capacity, and a 137L cargo container, the REDSTONE 1000 R2 DL is built to carry everything the job requires, on top of a hitch ball ready for towing.
TFT Dashboard, Safety & Comfort
A TFT dashboard with Bluetooth connectivity, keyless start, and a gear indicator work alongside ABS brakes, Electric Power Steering (EPS), full LED lighting, heated grips and heated seat, and onboard USB charging, keeping every ride safe, connected, and comfortable.

Tech Specs

  • Front wheel

    14in. aluminum

    Front suspension

    Dual A-arm with sway bar

    Front suspension travel (mm)

    230

    Front shock absorber

    Adjustable gas shock absorber

    Front tyre

    27×9×14in., Wanda

    Rear wheel

    14in. aluminum

    Rear suspension

    Independent torsional trailing arm

    Rear suspension travel (mm)

    230

    Rear shock absorber

    Adjustable gas shock absorber

    Rear tyre

    27×11×14in., Wanda

    Front brakes

    Disc, 1-piston caliper

    Front brakes diameter (mm)

    220

    Rear brakes

    Disc, 1-piston caliper

    Rear brakes diameter (mm)

    220

    Parking

    Mechanical

    Front Wheel-track (mm)

    1020

    Rear Wheel-track (mm)

    965

    Maximum allowed gradient (degree)

    30

  • Curb Weight (kg)

    510

    Seat height (mm)

    980

    Overall LxWxH (mm)

    2370×1280×1520

    Ground clearance (mm)

    300

    Minimum turning diameter (mm)

    7200

    Wheelbase (mm)

    1500

    Top speed (km/h)

    110

    Max load (kg)

    795

    Front rack capacity (kg)

    45

    Rear rack capacity (kg)

    90

    Seating capacity

    2

    Hitch towing rating (tralier without brakes)

    320

    Fuel capacity (L)

    30

    Approach angle (degree)

    80.5

    Departure Angle (degree)

    90

    Cargo container volume (L)

    137

  • Displacement (c.c)

    997.1

    Type

    V-twin cylinder / 4-stroke / DOHC

    Bore × stroke (mm)

    92×75

    Max power

    102.0 CV @ 7500 rpm

    Max.torque (N·m/rpm)

    98.3/6500

    Compression ratio

    11.5:1

    Fuel system

    EFI

    Ignition

    T.C.I

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling system

    Liquid-cooled

  • Gearbox

    CVT

    Final drive

    Shaft

  • ABS

    Yes

  • Dashboard type

    TFT, 7 inch

    USB charging port

    Yes

    Keyless start system

    Yes

  • EPS

    Included

    Hitch Ball

    Included

    Steel rope winch

    Included

    Bumper

    Included

    Diff lock

    Included
