REDSTONE 550 DL
Agile on Every Trail.
Price From
N/A
Power
42.6 CV @ 8000 rpm
Max. Torque
41.3/5000
Curb Weight (KG)
489
Compact, Agile Chassis
Built on the same Cr-Mo steel frame platform as the REDSTONE family but in a lighter, more compact size, the REDSTONE 550 DL is engineered to be agile on tight trails without giving up stability.
Built on the same Cr-Mo steel frame platform as the REDSTONE family but in a lighter, more compact size, the REDSTONE 550 DL is engineered to be agile on tight trails without giving up stability.
498.4cc DOHC V-Twin Engine
A 498.4cc 4-stroke DOHC V-Twin engine with EFI and liquid cooling delivers 31.3kW at 8,000 rpm and 41.3N·m of torque at 5,000 rpm, paired with a smooth CVT gearbox and shaft drive for confident power delivery on any terrain.
A 498.4cc 4-stroke DOHC V-Twin engine with EFI and liquid cooling delivers 31.3kW at 8,000 rpm and 41.3N·m of torque at 5,000 rpm, paired with a smooth CVT gearbox and shaft drive for confident power delivery on any terrain.
Selectable 2WD/4WD with Diff-Lock
Switch between 2WD and 4WD with a locking rear differential for precise control on grass, dirt, or rock, whatever the trail demands.
Switch between 2WD and 4WD with a locking rear differential for precise control on grass, dirt, or rock, whatever the trail demands.
Long-Travel Suspension
A Dual A-Arm front suspension with sway bar and an Independent Torsional Trailing Arm rear suspension, both with 230mm of travel and adjustable gas shocks matching the flagship REDSTONE 1000 R2 DL, keep the 550 DL planted and in control over rough ground.
A Dual A-Arm front suspension with sway bar and an Independent Torsional Trailing Arm rear suspension, both with 230mm of travel and adjustable gas shocks matching the flagship REDSTONE 1000 R2 DL, keep the 550 DL planted and in control over rough ground.
Cargo & Payload Capacity
With a 660kg payload capacity, 35kg front and 50kg rear rack capacity, and a 137L cargo container, the REDSTONE 550 DL carries everything the ride requires, on top of a hitch ball ready for towing.
With a 660kg payload capacity, 35kg front and 50kg rear rack capacity, and a 137L cargo container, the REDSTONE 550 DL carries everything the ride requires, on top of a hitch ball ready for towing.
TFT Dashboard, Safety & Comfort
A TFT dashboard with Bluetooth connectivity, keyless start, and a gear indicator work alongside ABS brakes, Electric Power Steering (EPS), full LED lighting, heated grips and heated seat, and onboard USB charging, keeping every ride safe, connected, and comfortable.
A TFT dashboard with Bluetooth connectivity, keyless start, and a gear indicator work alongside ABS brakes, Electric Power Steering (EPS), full LED lighting, heated grips and heated seat, and onboard USB charging, keeping every ride safe, connected, and comfortable.
Tech Specs
Front wheel
14in. aluminum
Front suspension
Dual A-arm with sway bar
Front suspension travel (mm)
230
Front shock absorber
Adjustable gas shock absorber
Front tyre
26×9×14in., Wanda
Rear wheel
14in. aluminum
Rear suspension
Independent torsional trailing arm
Rear suspension travel (mm)
230
Rear shock absorber
Adjustable gas shock absorber
Rear tyre
26×11×14in., Wanda
Front brakes
Disc, 1-piston caliper
Front brakes diameter (mm)
220
Rear brakes
Disc, 1-piston caliper
Rear brakes diameter (mm)
220
Parking
Mechanical
Front Wheel-track (mm)
1020
Rear Wheel-track (mm)
965
Maximum allowed gradient (degree)
30
